Mono filament Yarn Extruder Machine for PP/PE Rope

Send Inquiry

Product Code : 186

Product Description

PP/HDPE Monofilament Plant

Ocean Extrusion offers PP/HDPE monofilament plant a highly reliable option to produce superior quality of monofilament yarns which are then applied to make plastic ropes, brushers, nets, mesh used in surgery, and many more products. PP/HDPE monofilament mach de is equipped with high quality components for higher production capacity. Production of monofilament line is also possible at low power consumption and most advantageous production speed.

Application

Rope
Niwar
Single Monofilament Thread

Fishing Net
Thread Fabric
Surgical Mesh

Furniture Cloth
Paper Industry
Mosquito Net

Technical Specification

PLANT MODEL	SCREW SIZE (MM)	Screw l/d ratio	FEED SECTION TYPE	NO. OF LINES	STATION WINDERS	MAX PRODUCTION CAPACITY	TOTAL CONNECTED LOAD(KW)	MAIN DRIVE (HP)	Polymer To be Proopsspd	Dimension of plant (feet)
							TOTAL CONNECTED LOAD(KW)	MAIN DRIVE (HP)		L	W	H
OESMF 50	50	28:1	Smooth Feed	80	6	40	42.6	10	PP/HDPE	60	20	8
OESMF 65	65	28:1	Smooth Feed	140	10	60	57	15	PP/HDPE	70	20	8
OESMF 75	75	28:1	Smooth Feed	240	14	90	69.8	25	PP/HDPE	70	20	8
OESMF 75	75	28:1	Smooth Feed	280	16	100	70	25	PP/HDPE	70	6	8
OESMF 90	90	28:1	Smooth Feed	400	24	150	111.6	50	PP/HDPE	90	20	8
OESMF 51	50	28:1	Smooth Feed	200	12	90	63.8	20	PP/HDPE	70	20	8
NOTE: THE INFORMATION IS PROVIDED FOR THE PURPOSE OF GUIDELINE & INDICATION ONLY AND DOESN'T FORM ANY KIND OF COMMITMENTS.
